11 HOMEDEPOT.COM
Please contact 1-866-646-4332 for further assistance.
5
□
6
Install the refrigerator door vertically onto the bottom
hinge. Take out the middle left hinge from the accessory
bag then assemble the middle left hinge on the left side
of the refrigerator.
□
Install the freezer door vertically into the center hinge. Take
out the left top hinge and left top hinge cover from accesso-
ry bag, assembly left top hinge, left top hinge cover and hole
cover.
Part Description Quantity
O Middle left hinge 1
1
1
1
P Left top hinge cover
Q Top left hinge
A Hole cap
O
A
P
Q
Pre-Installation
To Next Page
