Vissani VXAR440BSS - Page 7

7
4
5
Removing the hinge pin
Installing the door
6
Installing the door hole covers
18
17
5
8
7
6
1
I
C
2
19
3
IC
IMPORTANT:
When reinstalling the door,
ensure that the top of the door is level with the
top of the cabinet and that the rubber gasket
makes a good seal with the cabinet all the way
around.
□ Remove the hinge pin (18) from the upper hinge
(17).
□ Flip the hinge over and reinstall the hinge pin on
the other side.
□ Install the door (C) onto the cabinet (I).
□ Install the upper hinge gasket (5),upper hinge (6)
and hinge cover (8) and
x by screws (7).
□ Install the door hole covers (1).
□ Take the door spindle cover (19) from the
accessory bag and install it on the top right side of
the door (C) by screw (3).
□ Install the door hole cover (2) on the top left side of
the door (C).
HOMEDEPOT.COM
Please contact 1-855-VISSANI (1-855-847-7264) for further assistance.
