VISSCHER CYPRESS - Page 28

F
2 1/2" #8 WASHER HEAD (#2 ROBERTSON)72X
Step 16
0515 Cypress - Bélinda 14x14 Instructions V1.1 EN
28X
Use two screws
per Panel
Fastened from inside
1) Fasten the Truss Frame Assembly to the structure from inside.

Inside view
