VISSCHER CYPRESS - Page 49

Step 34
0515 Cypress - Bélinda 14x14 Instructions V1.1 EN
1) Attach the Bottom Foam Closure (DC 2823) in all Roof Sheets.

2823 Bottom Foam Closure
Bottom view
4X
7041 RS (Outside left) 7042 RS (Inside left) 7043 RS (Middle) 7044 RS (Inside right)
7045 RS (Outside right)
14’ Roof Sheets
Foam Closure must
be placed over the
bottom row of holes
No need of Foam Closure
on the rib that will overlap
another rib.
