Vitalmaxx 917FS - Parts List

EN 22
Parts List
Part
No.
Description Num-
ber
Dimensions
1 Handlebar 1
2 Washer, curved 2 Ø 16 (Ø 8.3) x 1.5 mm
3 Spring washer 2
4 Hexagon socket bolt 2 M8 x 35 mm
5 Computer holder 1
6 Training computer 1
7 Cross-head bolt 1 M4 x 12 mm
8 Jack plug 1
9 Bicycle frame 1
10 Right pedal 1
11 Cap nut 4 M8
12 Washer, curved 4 Ø 16 (Ø 8.3) x 1.5 mm
13 Foot 2
14 Square-head bolt 4 M8 x 50 mm
15 Left pedal 1
16 Adjusting knob 1
17 Seat holder 1
18 Self-locking nut 3
19 Washer, straight 3
20 Seat 1
21 Locking pin 1
