Front Fender and Headlight Installation
Step 1: Finding the headlight, bolt, spacer, align them together,
and let the bolts pass through the headlight mounting holes,
spacer , and front fender hole correctly.
Step 2: Adjusting the headlight to the center posi-
tion, and use a 5mm hexagonal tool to gradually
tighten the nut to fasten the headlight.
Step 3: Using bolts to install the left and right brackets of
the front fender on the front fork to fasten the front fender.
Step 4: Aligning the arrow icon on the headlight connector
and connect the headlight connector to the cable connector
at the another end.
1 2
3 4
P6
