19
max. 15m
max. 7,5m
<
20°
0,5m
Ceiling with an inclination
angle <_ 20 ° are to be
treated as horizontal ceiling
Example of the detector
arrangement in large hallways
with a maximum width of 3m
Example of the detector
arrangement for surfaces
<_ 60 m² 60 m in corner areas
Example of the detector arrangement
for surfaces <_ 60 m² in corner areas
