19
English
Installation Torque:
35 lb-in(40kg-cm)
4. Tighten the straps using a pincer plier and a at blade screwdriver.
The corresponding mounting holes and cameras are shown below:
Combination
Compatible Models Screw
Direct installation:
AM-52E
A: FD9360-H, FD9380-H M4x8L
B: IT9388-HT
C: IT9360-H, IT9380-H
5.5 ~ 6.4mm
6. Install the AM-52E to the bracket and install your camera to the AM-52E adapter
bracket.
