Vivotek FD9166-HN User Manual

VIVOTEK
User's Manual - 137
To start a module, select the checkcircle in front, and click the
Start
button.
If you should need to remove a module, select the checkcircle in front and then click the
Stop
button. By then the module status will become
OFF
, and the
X
button will appear at
the end of the row. Click on the
X
button to remove an existing module.
When prompted by a conrm message, Click
Yes
to proceed.
Yes
No
Note that the actual memory consumed while operating the module will be indicated on the
Memory status
eld. This helps determine whether a running module has consumed too
much of system resources.
To utilize a software module, acquire the software package and click
Browse
and
Upload
buttons. The screen message for a successful upload is shown below:

Vivotek FD9166-HN Specifications

General

Brand	Vivotek
Model	FD9166-HN
Category	Security Camera
Language	English
