VIVOTEK
22 - User's Manual
6. Install the sunshield.
icro
AU+
AU-
MIC P
MIC N
DO+ (5V)
DO-
DI+
DI-
7. If used, connect the DI/DO, or audio wires to the terminal connectors.
