VIVOTEK
User's Manual - 117
■ Event name: Enter a name for the event setting.
■ Enable this event: Select this checkbox to enable the event setting.
■ Priority: Select the relative importance of this event (High, Normal, or Low). Events with a higher
priority setting will be executed rst.
Detect next motion detection or digital input after
seconds: Enter the duration in seconds to pause
motion detection after a motion is detected. This can prevent event-related actions to take place too
frequently.
1. Schedule
Specify the period of time during which the event trigger will take effect. Please select the days of the
week and the time in a day (in 24-hr time format) for the event triggering schedule. For example, you
may prefer an event to be triggered only during the off-ofce hours.
2. Trigger
This is the cause or stimulus which denes when to trigger the Network Camera. The trigger source can
be congured to use the Network Camera’s built-in motion detection mechanism or external digital input
devices.
There are several choices of trigger sources as shown on the next page.
Select the item to display the
detailed conguration options.
■ Video motion detection
This option makes use of the built-in motion detection mechanism as a trigger source. To enable this
function, you need to congure a Motion Detection Window rst. For more information, please refer to
Motion Detection on page 130 for details.
■ Periodically
This option allows the Network Camera to trigger periodically for every other dened minute. Up to 999
minutes are allowed.
■ System boot
This option triggers the Network Camera when the power to the Network Camera is disconnected and
re-connected.
■ Recording notify
This option allows the Network Camera to trigger when the recording disk is full or when recording
starts to overwrite older data.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Vivotek IB9368-HT and is the answer not in the manual?

Vivotek IB9368-HT Specifications

General IconGeneral
Built-in HDDNo
Flash memory128 MB
Internal memory256 MB
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
FocusMotorized
Digital zoom48 x
Number of lenses1
Focal length range2.8 - 12 mm
Maximum aperture number2.8
Minimum aperture number1.4
Sensor typeCMOS
Optical sensor size1/2.9 \
Total megapixels2 MP
Maximum resolution1920 x 1080 pixels
Supported video modes1080p
Image quality adjustmentBrightness, Contrast, Saturation, Sharpness
Video compression formatsH.264, H.265, M-JPEG
Noise reduction technology3D noise reduction
Supported graphics resolutions1920 x 1080 (HD 1080)
Tilt angle range0 - 90 °
Angle of rotation180 °
Camera shutter speed1/5 - 1/32000 s
Minimum illumination0.055 lx
TypeIP security camera
CertificationCE, FCC Class B, UL, LVD, VCCI, C-Tick
Placement supportedIndoor & outdoor
Connectivity technologyWired
LED typeIR
Night vision distance30 m
Number of illumination LEDs2
Signal-to-Noise Ratio (SNR)68 dB
Number of users10 user(s)
Networking standardsIEEE 802.1x, IEEE 802.3af
Ethernet interface typeFast Ethernet
Supported network protocols802.1X, ARP, CIFS/SMB, CoS, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, PPPoE, QoS, RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS, UDP, UPnP, ONVIF
IK codeIK10
Form factorBullet
Mounting typeWall
Product colorBlack, White
LED indicatorsPower, Status, System
International Protection (IP) codeIP66
Power source typePoE
Power consumption (max)12.95 W
Power consumption (typical)9 W
Operating temperature (T-T)-30 - 60 °C
Operating relative humidity (H-H)0 - 90 %
Mac operating systems supportedMac OS X 10.12 Sierra
Windows operating systems supportedWindows 7, Windows 8
Weight and Dimensions IconWeight and Dimensions
Depth85 mm
Width214.5 mm
Weight738 g
