Vivotek IB9387-H User Manual

VIVOTEK
User's Manual - 7
Some of the sufx syntax used in model naming are listed below:
E w/ heater for extreme weather
Fx Focal length w/ number
T w/ Remote focus lens
R w/ PoE repeater
H w/ High Dynamic Range functionality
NOTE:
IMPORTANT:
The E model camera comes with an embedded heater and requires an 802.3at PoE
switch or 12V/24V 2A power.
1
2
3
4
6
5
8
7
10
LAN/PoE
100~240V
AC
ON
OFF
9
GE LAN GE LAN
802.3at
12/24V 1A or 2A
Operating
Temperature
Consumption & Power Input
-40ºC ~ 0ºC, heater
on
PoE 802.3at - max. 24W (PoE Plus mid-span or switch)
-40ºC ~ 0ºC, heater
on
DC 12V input - 2.5A
≥0ºC, heater off DC 12V input - 1A
