VIVOTEK
316 - User's Manual
>_maxpan
axisy capability_ptz_c<0~(n-1)
>_mintilt ~
capability_ptz_c<0~(n-1)
>_maxtilt
1/4 Custom home tilt position.
axisz capability_ptz_c<0~(n-1)
>_minzoom ~
capability_ptz_c<0~(n-1)
>_maxzoom
1/4 Custom home zoom position.
axisf capability_ptz_c<0~(n-1)
>_minfocus ~
capability_ptz_c<0~(n-1)
>_maxfocus
1/4 Custom home focus position.
axisflip <boolean> 1/4 Custom home flip side.
returnhome <boolean> 1/4 Enable/disable return home while idle.
returnhomeinterval 1~999 1/4 While idle over this time interval, idle
action will be taken.
digitalzoom <boolean> 1/4 Enable/disable digital zoom
idleaction_enable <boolean> 1/4 Enable/disable idle action while idle
idleaction_type pan,patrol,home,objtrack,
prev
1/4 This field tells what kind of action should
be taken while idle.
idleaction_interval 1~999 1/4 While idle over this time interval, idle
action will be taken.
zoomenhance <boolean> 1/4 Enable /disable zoom enhancement
tour_index -1, 0~19 1/4 Index of the enabled tour group, from 0
to 19.
Set -1 to disable all the tour groups.
tour_i<0~19>_name string[40] 1/4 Name of the tour.
tour_i<0~19>_type <boolean> 1/4 0 = Recorded tour
1 = Preset tour
tour_i<0~19>_speed -5 ~ 5 1/4 Preset tour: pan and tilt speed when
moving between presets.
Recorded tour: unnecessary.
tour_i<0~19>_direction forward,backward,random 1/4 User can choose which direction the
preset tour goes.
"forward": preset tour goes in forward
order.
"backward": preset tour goes in
backward order.
