VIVOTEK
User's Manual - 319
paritybit none,
odd,
even
4/4 For error checking.
stopbit 1,2 4/4 "1": One stop bit is transmitted to indicate the
end of a byte.
"2": Two stop bits are transmitted to indicate
the end of a byte.
If you want to transfer the stopbit for 150% of
the normal time used to transfer one bit, the
uart_i<0~(n-1)>_stopbit should be set as 2
and the uart_i<0~(n-1)>_databit set as 5 as
well.
uartmode rs485 4/7 RS485 mode.
7.45 Lens configuration
Group: lens for n channel products
n denotes the value of "capability_nvideoin"
(capability.image.c<0~(n-1)>.lensconfiguration.support = 1)
NAME VALUE SECURITY
(get/set)
DESCRIPTION
selected <string> 6/7 Current selected lens profile.
e.g. lens_selected=lens_default_i0, it means
choosen lens configuration is i0 lens of default
group.
Group: lens_default
NAME VALUE SECURITY
(get/set)
DESCRIPTION
totalnumbers 0,<positive integer> 6/7 Totoal support number of the default lens
profiles
Group: lens_user
NAME VALUE SECURITY
(get/set)
DESCRIPTION
totalnumbers 0,<positive integer> 6/7 Totoal support number of the user lens profiles
Group: lens_default_i<0~(n-1)> n is lens_default_totalnumbers
NAME VALUE SECURITY DESCRIPTION
