VIVOTEK
6 - User's Manual
Some of the sufx syntax used in model naming are listed below:
E w/ heater for extreme weather
Fx Focal length w/ number
T w/ Remote focus lens
R w/ PoE repeater
H w/ High Dynamic Range functionality
NOTE:
IMPORTANT:
The IB9391-EHT comes with an embedded heater and requires an 802.3at PoE
switch or 12V/24V 2A power.
1
2
3
4
6
5
8
7
10
LAN/PoE
100~240V
AC
ON
OFF
9
GE LAN GE LAN
802.3at
12/24V 1A or 2A
Operating Temperature Consumption & Power Input
≥-10ºC PoE - 24.8W (PoE Plus mid-span or switch)
42.5V(0.58A) - 57V(0.43A)
≥-40ºC, heater on 12/24V input - 2A. 24V - max. 21.8W, 1.65A(PF0.55);
12V - max. 19.5W, 1.625A
≥-10ºC, heater off 12/24V input - 1A.
NOTE:
1. The camera is only to be connected to PoE networks without routing to outside plants.
2. For PoE connection, use only UL listed I.T.E. with PoE output.
1. La caméra ne doit être raccordée qu’à des réseaux PoE, sans routage vers des installations
extérieures.
2. Pour les raccordements PoE, utilisez uniquement un équipement de TI homologué UL, avec une
sortie PoE.
IMPORTANT:
Please contact VIVOTEK's certied dealers for power adapters.
