Vizio D32h-C0 User Manual

5
26
$GMXVWLQJWKH&RORU&DOLEUDWLRQ6HWWLQJV
Color Calibration Settings allow you to make precise adjustments to
the picture and to create picture modes to save groups of picture
settings.
The Color Tuner, 11 Point White Balance, and test
patterns allow technicians to manually calibrate the TV.
Calibration requires specialized training, an input with
precisely set colors, and a specialized light meter.
To adjust the color calibration picture settings:
1. From the PICTURE menu, use
the Arrow buttons to highlight
&RORU&DOLEUDWLRQ and press
the OK button. The COLOR
CALIBRATION menu is displayed.
2. Use the Arrow buttons to
highlight the setting you wish to
adjust, then press the OK button
to change the setting:
• 3LFWXUH0RGH - Not directly
selectable (reference only).
• Color Temperature - Not
directly selectable (reference
only). Changes to Hue,
Saturation, Brightness,
2΍VHWDQG*DLQDUHVDYHG
here and indicated with an
asterisk (*).
• Color Tuner$GMXVWWKH+6%FRORU5*%R΍VHWVDQG
11-point white balance, and display calibration test
patterns.
VI
ZI
O
COLOR CALIBRATION
Picture Mode Calibrated
Color Temperature Normal
Color Tuner
Reset Color Tuner
• 5HVHW&RORU7XQHU - Resets the color tuner settings for the
current color temperature mode.
• If the current picture mode is a pre-set, the color
temperature is reset for all pre-set picture modes using
WKHFXUUHQWFRORUWHPSHUDWXUHPRGHΖWGRHVQRWD΍HFW
saved custom picture modes.
• If the current picture mode is a saved custom picture
mode, the color temperature only reset for that custom
SLFWXUHPRGHVΖWGRHVQRWD΍HFWSUHVHWSLFWXUHPRGHV
or other custom picture modes.
For example, suppose that:
• You have created two custom picture modes: “My Picture
Settings” and “Oliver.” They both use the Normal color
temperature, but you have adjusted it for each of the
modes.
—and—
• You have changed the Color Tuner settings for the
Normal color temperature while in the Calibrated picture
mode.
6R\RXKDYHȊ0\3LFWXUH6HWWLQJVȋZLWKDPRGLȴHG1RUPDO
FRORUWHPSHUDWXUHȊ2OLYHUȋZLWKGL΍HUHQWFKDQJHVWRWKH
Normal color temperature, and a third set of changes to the
Normal color temperature that applies to all of the pre-set
picture modes.
The Calibrated and Calibrated Dark picture modes both use
the Normal color temperature. If Calibrated is the current
picture mode when the Normal color temperature is reset,
WKHFKDQJHD΍HFWVERWKRIWKHVHSLFWXUHPRGHVEXWGRHV
not undo the changes to the color temperature for the “My
Picture Settings” or “Oliver” custom picture modes.
If “My Picture Settings" is the current picture mode when
the Normal color temperature is reset, the change only
D΍HFWVWKHȊ0\3LFWXUH6HWWLQJVȋSLFWXUHPRGH7KHFRORU
temperature changes to the “Oliver,” Calibrated, and
Calibrated Dark picture modes stay as they are.

Vizio D32h-C0 Specifications

General

Screen shape	Flat
LED backlight	Yes
Response time	- ms
Display diagonal	32 \
Display brightness	- cd/m²
Display resolution	1366 x 768 pixels
Display technology	LED
Native aspect ratio	16:9
Native refresh rate	60 Hz
LED backlighting type	Full-Array
Supported video modes	720p
Contrast ratio (dynamic)	200000:1
Display number of colors	16.7 million colors
Cables included	AC
Package type	Box
Package depth	134.1 mm
Package width	785.1 mm
Package height	564.9 mm
Package weight	6500 g
Remote (IR) output	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Panel mounting interface	100 x 100 mm
Audio decoders	DTS Studio Sound, DTS TruSurround
RMS rated power	10 W
AC input voltage	120 V
Power consumption (standby)	0.5 W
Power consumption (typical)	29.1 W
Number of OSD languages	3
On Screen Display (OSD) languages	ENG, ESP, FRE

Weight and Dimensions

Depth (with stand)	199.9 mm
Width (with stand)	729.2 mm
Height (with stand)	484.6 mm
Weight (with stand)	4699 g
Depth (without stand)	73.9 mm
Height (without stand)	434.6 mm
Weight (without stand)	4300 g
