Vizio E43-E2, E50-E1, E50x-E1, E50-E3, E55-E1, E55-E2,E60-E3 - Page 25

English - 25
To connect your Display to an external audio speaker:
1. Verify that your external audio speaker has an audio input that matches an available output on the
Display. (HDMI, 3.5mm, etc.) Note: HDMI connections must be connected to the HDMI-ARC port.
2. Turn both the Display and external audio speaker o.
3. Connect the appropriate cable (not included) to the Display and the external audio speaker.
4. Turn both the Display and external audio speaker on.
HDMI
CABLE
• CEC 2-WAY COMMUNICATION
• 2.0 - 5.1 DIGITAL AUDIO
• HDMI ARC ONLY AVAILABLE HDMI 1
• PCM, DTS, DOLBY DIGITAL
Sound bar system
Audio Receiver
DIGITAL
OPTICAL
CABLE
• 2.0 - 5.1 DIGITAL AUDIO
• PCM, DTS, DOLBY DIGITAL
COMPOSITE
CABLE
• ANALOG STEREO CONNECTION
• 2.0 CHANNEL
*External sound speakers and systems sold separately.
