Vizio E50x-E1, E55-E1, E65-E1 - Page 25

English - 25
E50x-E1 E55-E1 E65-E1
Screw Size: M6 M6 M6
Hole Pattern: 200 mm (V) x 200 mm (H) 200 mm (V) x 200 mm (H) 400 mm (V) x 400 mm (H)
Weight w/o Stand:
26.68 lb
(12.10 kg)
34.06 lb
(15.45 kg)
50.04 lb
(22.70 kg)
Wall-mount screw locations.
Note: The image shown here is for illustrative purposes only and may be subject to change. The actual number of ports and their locations may vary, depending on the model.
