7 Adjustment
7.1 White Balance Adjustment
1. Enter factory model，step MENU+ 1999+last ;
2. This TV adjust YPbPr source，example YPbPr source Normal temperature;
3. Choose “Current Source” to YPbPr whit remote control，“Color temp” as NORMAL;
4. Choose “WB Patten”=818（normal，computer，cool color temperature）;
5. Adjust R,G,B GAIN value，in order to the color temperature，luminance meet specifications;
6. The value of R,G,B GAIN should be app：
7. Check the sources of HDMI and AV，if color temperature over the specifications，please adjust it as YPbPr.
8. Temperature spec：
9. MAX luminance（cool） >250
MIN MAX MIN MAX MIN MAX
R GAIN 80 140 80 140 50 150
G GAIN 75 128 75 120 50 145
B GAIN 80 134 80 132 60 130
Normal Computer Cool
x (center)
0.313 0.003 0.285 0.003 0.276 0.003
y (center)
0.329 0.003 0.293 0.003 0.282 0.003
