Vizio E55-C1 Service Manual

38
VDD_1P8
LNA_INN
LNA_INP
C162
1P 50V
ADJ(GND)
1
VOUT
2
VIN
3
4
4
U102
AP1117E33L-13-77
C131
100N16V
+
C132
100UF 16V
+5V_SW
+3V3TUNER
FAT_IN- 5
GND 3,4,5,7,8,9,10,11,12,13,14,15
FAT_IN+ 5
IF_AGC 5
C127
47PF 50V
OSDA2 5
OSCL2 5
IF_AGC
FAT_IN+
FAT_IN-
OSCL2
OSDA2
5V_SW TO +3V3TUNER
VER.B 9/29
TUNER POW ER +3V3
AP1117E33L-13-77 SOT223 1A/3.3V
MxL661
Silicon Tuner
C169
5P6 50V
VDD_1P8
L102
27nH
T_SCL
T_SDA
RESET
NEARLY IC
R160 10K
C184
47nF 16V
LNA_INN
LNA_INP
C160
1000pF 50V
1
1
2
2
3
3
4
4
ANT
5
FCN101
RF CONN
C161
1000pF 50V
L101
NC
3
1 2
D107
BAV99
C159
1000pF 50V
L105
27nH
IN-
FAT_OUTP
FAT_OUTN
Near CHIP
FAT_IN+
R161 51R
C134
100N16V
R155
100R 1/16W 5%
FAT_IN-
IN+
R158 51R
R173
330R 1/16W 5%
C148
NC/47PF 50V
C139
33P 50V
Near tuner
C133
100N16V
C138
33P 50V
R157
100R 1/16W 5%
C130
100N16V
T_SCL
T_SDA
R470
4.7K 1/16W
R159 100R 1/16W 5%
+3V3TUNER
R172
0R05 1/16W
R171
0R05 1/16W
R153 100R 1/16W 5%
C175
1uF 10V
VDD_3p3
1
LNA_INP
2
LNA_INN
3
VDD_1p8
4
AGC_2/GPO_3
5
AGC_1
6
IF_OUTP_2/GPO_1
7
IF_OUTN_2/GPO_2
8
IF_OUTP_1
9
IF_OUTN_1
10
VDD_3p3
11
VDD_1p8
12
VDD_1p2
13
GND_DIG
14
VDD_IO
15
SCL
16
SDA
17
CLK_OUT
18
XTAL_N
19
XTAL_P
20
GND_XTAL
21
VDD_1p8
22
RESET_N
23
AS
24
E-PAD
25
U104
MxL661-AG-R
R469
4.7K 1/16W
VDD_1P8
C149
NC/47PF 50V
Ground size needs to be larger for thermal
Ver.B
0806_8.2pэ4.7pэ 到繵熬
+3V3TUNER
+3V3TUNER
L103
8.2NH
AGC1
C177 4.7NF 50V
R183
510K 1%
C171
100N16V
C123
1uF 10V
C135
100N16V
1 2FB104 1000OHM
+3V3TUNER
C167
100N16V
C176
2.2nF 50V
C163
100N16V
C168 4.7NF 50V
R126
1K 1/16W 1%
C170
100N16V
C166
10N 50V
AGC1
FAT_OUTP
FAT_OUTN
C165
4.7PF 50V
C164
4.7PF 50V
1 2
X102
16MHz
+3V3TUNER
C126
47PF 50V
OEM MODEL Size
Rev
Date
Sheet of
TPV MODEL
PCB NAME
称 爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬 隔 瓜 絪 腹
A
B
6 15Wednesday , October 15, 2014
715G7126-M0A-000-0040
06. Tuner In

Vizio E55-C1 Specifications

General

Color depth	8 bit
Screen shape	Flat
Response time	- ms
Display diagonal	54.6 \
Display brightness	- cd/m²
Native aspect ratio	16:9
LED backlighting type	Full-Array
Supported video modes	1080p
Contrast ratio (dynamic)	500000:1
Display refresh rates supported	120 Hz
Motion interpolation technology	-
Music apps	Pandora, Spotify
Video apps	Netflix, YouTube
Lifestyle apps	Facebook, Twitter
Audio decoders	DTS Studio Sound
RMS rated power	10 W
Number of speakers	2
PC in (D-Sub)	No
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Wi-Fi standards	Wi-Fi 4 (802.11n)
On Screen Display (OSD) languages	ENG, ESP, FRE
Product color	Black
Panel mounting interface	300 x 300 mm
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.5 W
Package depth	160 mm
Package width	1357 mm
Package height	821.9 mm
Package weight	21000 g
Sustainability certificates	ENERGY STAR
Certification	UL, cUL, NOM, FCC Class B, BET7/ICES-003 Class B, IC, IFETEL, HDMI (CEC, ARC), Dolby Digital

Weight and Dimensions

Stand width	1090 mm
Depth (with stand)	255 mm
Height (with stand)	781 mm
Weight (with stand)	15900 g
Depth (without stand)	64.01 mm
Width (without stand)	1239 mm
Height (without stand)	721.1 mm
Weight (without stand)	15500 g
