To mount your Display on a wall, you will need a wall mount. Consult
the information on this page to nd the appropriate mount for your
Display.
Be sure the mount you choose is capable of supporting the
weight of the Display. After you have determined that you have
the correct mount for your Display, you can begin the installation.
To install your Display on a wall:
1. Disconnect any cables connected to your Display.
2. Place the Display face-down on a clean, at, stable surface. Be sure the
surface is clear of debris that can scratch or damage the Display.
3. Remove the stands by loosening and removing the screws.
4. Attach your Display and wall mount to the wall, carefully following the
instructions that came with your mount. Use only with a UL-listed wall
mount bracket rated for the weight/load of this Display.
WALL-MOUNTING THE DISPLAY
Installing a Display on a wall requires lifting.
To prevent injury or damage to the Display,
ask someone to help you.
E55-E1 E55-E2 E60-E3 E65-E0 E65-E1 E70-E3 E75-E1 E75-E3 E80-E3
Screw Size: M6 M6 M6 M6 M6 M6 M8 M6 M6
Hole Pattern:
200 mm (V)
x 200 mm (H)
200 mm (V)
x 200 mm (H)
400 mm (V)
x 400 mm (H)
400 mm (V)
x 400 mm (H)
400 mm (V)
x 400 mm (H)
400 mm (V)
x 400 mm (H)
400 mm (V)
x 400 mm (H)
400 mm (V)
x 400 mm (H)
400 mm (V)
x 400 mm (H)
Weight w/o Stand:
26.68 lb
(12.10 kg)
34.39 lb
(15.60 kg)
43.65 lb
(19.8 kg)
50.72 lb
(23 kg)
50.72 lb
(23 kg)
56.88 lb
(25.8 kg)
77.16 lb
(35 kg)
62.83 lb
(28.5 kg)
31.97 lb
(14.90 kg)

Vizio E60-E3 Specifications

General

Screen Type	led
Wall Mount	400mm x 400mm
Features	xled, xtreme black engine w/ 12 local dimming zones, vizio smartcast, compatible with google assistant and amazon alexa
Tuner	not included
Screen Size	60 inches
Refresh Rate	120hz
Closed Captioning	yes
Motion Enhancement	clear action 180
HDR	yes
Built-In Speakers	yes
Surround Sound	dts studio sound
Speakers Output	20 watts
HDMI ARC Ports	yes
USB Ports	1
Ethernet	yes
RF Antenna	yes
Bluetooth	true, 4.1
Network	built-in wi-fi
Digital Optical Audio Outputs	1
Analog Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	0
DVI	0
VGA Ports	0
Smart Applications	amazon alexa, google assistant
Remote Control	standard
3D	no
Depth with Stand	10.6 inches
Height with Stand	33.5 inches
Width with Stand	53.5 inches
Net Weight with Stand	44.5 pounds
Depth without Stand	2.7 inches
Height without Stand	31 inches
Net Weight without Stand	43.7 pounds
