To install the TV stand:
1. Place the TV screen-down on a clean, flat surface. To prevent
scratches or damage to the screen, place the TV on a soft
surface, such as carpet, rug, or blanket.
2. Push the neck up through the bottom of the stand.
3. Insert and tighten the six (6) screws as shown above.
4. Insert the assembled stand into the bottom of the TV. Tighten
the four (4) screws as shown above.
5. Move the TV with attached stand into an upright position
and place on a flat, level, and stable surface.
6. To ensure proper ventilation, leave at least 1” of space
between the back of the TV and any other objects (walls,
etc).
STEP 3 STEP 4
