Connecting a device — AUDIO & VIDEO CABLE TYPES
Your TV can be used to display output from most devices.
1. Verify that your device has a video port that matches an available port on the TV (HDMI, Composite, etc.).
HDMI CABLE
HDMI
COAXIAL CABLE
Coaxial
2. Connect the appropriate cable (not included) to the TV and the device.
3. Turn the TV and your device on.
4. Set the TV’s input to match the connection you used (HDMI-1, HDMI-2, etc.).
COMPOSITE (AV) CABLE
Y
L
R
Connecting a device — AUDIO CABLE TYPES
HDMI CABLE
Your TV can be output sound to an audio device, such as a receiver or sound bar.
HDMI
1. Verify that your device has an audio port that matches an available port on the TV (optical, RCA, etc).
2. Connect the appropriate cable (not included) to the TV and the device.
COMPONENT AND/OR COMPOSITE CABLE
3. Turn the TV and your device on.
R
L
OPTICAL/SPDIF CABLE
Optical
Note: The actual ports and their locations may vary, depending on the TV model.
3

Vizio V755-J04 Specifications

General

Screen shape	Flat
Response time	10 ms
Display diagonal	75 \
Display brightness	- cd/m²
Display technology	-
Native aspect ratio	16:9
Native refresh rate	60 Hz
LED backlighting type	Full-Array
Display diagonal (metric)	189.23 cm
Supported graphics resolutions	3840 x 2160
Number of tuners	1 tuner(s)
High Dynamic Range (HDR) technology	Dolby Vision, High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Stand type	Connected stand
Product color	Black
Panel mounting interface	400 x 400 mm
HDMI ports quantity	3
USB 2.0 ports quantity	1
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
RMS rated power	8 W
Number of speakers	2
Cables included	AC
Remote control type	XRT260
Package type	Box
Package depth	225.8 mm
Package width	1895.1 mm
Package height	1145.5 mm
Package weight	37700 g
Power consumption (typical)	- W

Weight and Dimensions

Depth (with stand)	335.3 mm
Width (with stand)	1686.6 mm
Height (with stand)	1043.9 mm
Weight (with stand)	27700 g
Depth (without stand)	78.7 mm
Height (without stand)	972.8 mm
Weight (without stand)	27200 g
