VM Motori MR704LX - Page 9

MR 700
9
Ed. 3 - 2012_11
English
Electrolytic zinc (K)
Wet exhaust gas
sleeve (G)
Air lter (H)
Turbocharger (D)
Coolant manifold (Z1)
Boiler connec-
tion (X)
Exhaust manifold (Z)
Fluid Cooler (A)
Electrolytic zinc (K)
Waste gate valve (F)
Thermostatic
valve (J)
