20
FN KEY FOR
OUTPUTS
BLUETOOTH
PHASE
SOUND COLOR
LOW OSR+HPC ON
LOW OSR+HPC OFF
HIGH LOW OSR+HPC ON
HIGH LOW OSR+HPC OFF
I2S DSD CHANNEL
DSDL = PCM DATA(The DSD left channel using the PCM DATA pin)
DSDL = PCM LRCK(The DSD left channel using the PCM LRCK pin)
Note: When using the I
2
S input to streaming DSD audio, if you find that
the left and right channels are incorrect, you can use this option to
correct it.
PRE MODE
PRE MODE is the volume adjustment function switch for the output interface.
VARIABLE: The output interface volume is controlled.
FIXED: The output interface volume is fixed.
