Description of Parts
① Lens Hood
② Filter Ring
③ Aperture Ring
④ Focus Ring
⑤ Depth of Field Scale
⑥ Mount Index Ring
⑦ Mount
⑧ Aperture Index
⑨ Aperture Scale
⑩ Distance Scale
⑪ Distance Index
⑫ Mount Index
①
⑨
⑩
⑪
⑫
⑧
②
③
④
⑤
⑥
⑦
