VOKERA Linea - Page 3

2
Linea
45 78
12
6
3
1. Pressure gauge
2. Clock aperture
3. N/A
4. Hot Water temperature selector
5. Mode selector switch
6. Status LED
7. Digital display
8. Heating temperature selector
Fig. 1
Fig. 2
INTRODUCTION
Filling valve
Filling Loop
Isolating valve
