8 9
10 11
VR648:
Tiles:
Fliesen:
Fliser:
Fliser:
Tegels:
Carreaux:
3 - 19 mm Standard
17 - 28 mm VR648+10
27 - 38 mm VR648+20
37 - 48 mm VR648+30
47 - 58 mm VR648+40
57 - 68 mm VR648+50
060 - VR648+
24 mm
3/4"
Ø60 mm
Ø2 3/8"
060A - VR2219+
01 234567 8910
Ø286 mm
Ø11 1/4"
7
VR2219
Std.
165 mm
6 1/2"
+100
265 mm
10 3/8"
+200
365 mm
14 3/8"
060A
060 + 060A:
Max. 360°
2,5 mm
12 mm
Extension Forlængerdele Verlengstukken
Verlängerung Förlängning Modification
Service - VR556
VR2219:
3 - 15 mm Standard
15 - 25 mm VR2219+10
25 - 35 mm VR2219+20
35 - 45 mm VR2219+30
45 - 55 mm VR2219+40
55 - 65 mm VR2219+50
12 mm
