CONTROLS
AND
EQUIPMENT
Pos .
Page
1
- Switch for electric
windows 45
2 - Remote controlled exterior
mirror
71
3 -
Light
switch 61
...
Headlight
range
control 62
...
Instrument and
switch lighting 62
4- Air vents Booklet 3.1.2
5 -
Turn
signal
and headlight
dip lever 64
Cruise control system 126
6 - Combi-instrument:
Instruments 6
Indicator lamps 17
On-board computer 25
Radio/navigation system11 24
7 - Windscreen wiper/washer lever .. 67
Multi-function
indicator 10
8-
Mobile
telephone1'with mounting 30
9 - Switch for emergency light
system 62
10 - Console for
-
Switch for roof fan 63
-
Switch for
rear window heating 73
-
Knurled wheel for left
seat
heating 78
-
Switch for ESP 129
-
Knurled wheel for right set heating 78
-
Switch for roof light and
separate interior light 63
11
- Radio1'or
Radio/navigation system1'
12 - Passenger Airbag Booklet 2.1
13 - Bonnet release handle 58
14 - Cold starting aid
(Diesel
engines)
124
15-Fuses
Booklet 3.2
16 - Driver's Airbag Booklet 2.1
17-
Horn (only functions with
ignition switched on)
18 -
Ignition
lock 121
19-Cigarette lighter/
electric
socket 112
20 - Auxiliary heater controls Booklet 3.1.2
21
- Ashtray 113
22-
Tachograph 16
23-
CD Changer1' 83
24 - Gear lever (manual
gearbox)
115
Selector lever (automatic
gearbox)
116
25 - Console for...
...
pull knob
differential
lock Booklet 3.2
...
Filter saturation display Booklet 3.2
26 - Controls
...
for heating/ventilation Booklet 3.1.2
...
for air conditioner... Booklet 3.1.2
...
for Climatronic Booklet 3.1.2
27 - Stowage compartment 82
•
There
are many possible equipment
combinations.
Therefore, the number and
position
of operating elements in the il-
lustration
may vary from those in your ve-
hicle.
•
Some of the items listed are only fitted
on certain models or are optional extras.
•
On right-hand drive vehicles the arrange-
ment of the switches and the location of
some items can vary. The symbols on the
switches are the same as for
left-hand
drive
vehicles.
"
Vehicles with a factory fitted radio, radio/na-
vigation system, mobile phone or CD changer
are supplied with a supplementary instruction
manual.
When
service installing
a
radio, please referto
the instructions in Booklet 3.2 under "Acces-
sories, modifications and replacement of
parts" and "Installing radio" or
"Mobile
tele-
phones and
2-way
radios".
COCKPIT
5
