Volt Resistance 12V - Connecting Controller to Battery Harness; Controller Operation and Power Settings; Power Status and System Load; Power Consumption and System Load

Instruction Booklet
www.voltheat.com
3
Let the battery harness plug hang a couple of inches below the seat on the
left side.
Use a tie-wrap or electrical tape to safely attach wire to the frame and other
points on the motorcycle to prevent the wire from shifting.
Double check that your battery terminal bolts and cabling are correct and
tight.
Your 12v heated clothing must always be used with a controller.
The single wire coming from the controller connects to the battery harness.
The dual wires from the controller connect to the 12v heated clothing.
To operate your controller press and hold the round power button and
select power setting:
Red = 100% | Yellow = 75% | Green = 50% | Flashing Green = 25%
If you have a problem, rst check all connections for tightness, and wires for
proper routing and insulation integrity, also check fuse in battery harness.
Other accessories use up the electrical power need to power your
heated clothing. Add up your power needs and subtract them from your
alternator’s peak power output (available from your manufacturer or
dealer). 12v Volt Gloves = 3 Amps | 12v Volt Jacket = 7 Amps
7.
8.
9.
1.
2.
3.
1.
2.
CONNECTING YOUR CONTROLLER TO THE
BATTERY HARNESS
POWER STATUS
