Ready to Install?
If you have already designed your system, and mounted
your transformer, use the Quick Start Guide Steps
starting on the next page.
START HERE
www.voltlighting.com
Quick Start Guide Steps
1. Read the safety instructions and unpack your transformer.
2. Mount your transformer.
3. Run wires from transformer location to xtures or hubs.
4. Attach all wires to transformer terminals. For each paired wire, attach one
side to a common terminal and the other side to the voltage terminal.
5. Check that all of your connections are secure.
6. Plug in your transformer.
7. Flip the ON/OFF breaker switch upward to power on your transformer.
8. Check that your transformer pilot light and timer pilot light are both on.
9. Turn your timer clockwise to manual “On” mode.
10. Check that all of your xtures are on and functioning properly.
11. Measure the voltage at xtures or hubs.
12. If needed, use another voltage terminal (some transformers only have
one).
13. Set your timer to the desired function.
14. Close the transformer door using the locking mehanism to seal the unit
from weather and debris.
15. At Dusk, make any last minute adjustments to your xtures. Bury the
wire only after you have made these adjustments.
