www.volta.com.tr
23
6. MAINTENANCE AND STORAGE
6.4 Brake Test
6.4.1 Drum Brake:
6.4.1.1 Press the joint section (1), tighten the setscrew (3), simultaneously
hold the brake lever (2) and tighten the brake (B-C) 1/3-1/2 of the designed
A-C distance
6.4.1.2 Place the brake in the drum and tighten at the best rate you consider
for tightness and performance.
6.4.1.3 Optimum braking is achieved when the distance between brake lining
and inner surface of drum is 1.5mm.
6.4.1.4 Replace the lining when it is half of the unused form.
6.4.2 Disc Brake
6.4.2.1 . The brake lever at the right side of the handlebar is for disk brake.
There is about 10-20 mm empty space between A-B positions.
6.4.2.2 . If, empty space is not 10-20 mm, this means the brake fluid is low.
Remove the C and D bolts and add brake fluid to the opened section.
10 - 20 mm
