Impressum /legal notice in our operating instructions
These operating instructions are a publication by Voltcraft
®
, Lindenweg 15, D-92242 Hirschau/Germany, Phone +49 180/586 582 7
(www.voltcraft.de).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfi lming, or the capture in electronic data processing
systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
These operating instructions represent the technical status at the time of printing. Changes in technology and equipment reserved.
© Copyright 2012 by Voltcraft
®
TECHNICAL DATA
Operating voltage: ...............................200 - 240 V/AC, 50-60 Hz
Input:.....................................................<3 W
Protection class: ...................................II
Sensor safety class: .............................IP68
Front plate safety class: ........................IP54
Assembly dimensions (W x H): .............71 x 30 mm
Dimensions of frontplate: ......................75 x 34.5 mm
Operating temperature: ........................0 °C to +60 C°
Humidity during operation: ....................20 - 85% rel. humidity, not condensing
Accuracy : .............................................±1 °C (at -40 °C to +70 °C), otherwise ±2 °C
Temperature range of sensor: ..............-40 °C to +120 °C
Sensor type: .........................................NTC, 10 kΩ at +25 °C
Resolution: ............................................0.1 °C (< 100°C)
..............................................................1 °C (>= 100°C)
Measuring rate: .....................................<= 2 seconds
Relay loading capacity: .........................max. 10 A/240 V/AC
CHANGING THE PASSWORD
• Select the setup menu (see “OPERATING FUNCTIONS” and then “Opening the setup
menu“). Enter the current password (factory setting: “111“).
• If „F01“ appears on the display, select the function “P01“ with the buttons “S” and “F”, and
press the button “
”.
• Set the fi rst digit of the password with the buttons “S” and “F” and briefl y press the “SET”
button. The display fl ashes briefl y if the value was changed.
• Select the function „P02“ with the buttons “S” and “F”, and press the button “
“.
• Set the second digit of the password with the buttons “S” and “F” and briefl y press the
“SET” button. The display fl ashes briefl y if the value was changed.
• Select the function „P03“ with the buttons “S” and “F”, and press the button “
“.
• Set the third digit of the password with the buttons “S” and “F” and briefl y press the “SET”
button. The display fl ashes briefl y if the value was changed.
• Keep the “SET“ button pressed until the current temperature is displayed again (approx. 3
seconds).
The new password is now saved.
RESETTING PASSWORD TO FACTORY SETTING
If you forgot your password, you can reset it to “111”. Proceed as follows:
• Separate the thermostat from the mains voltage.
• Keep both buttons “
“ and “SET“ pressed at the same time, and switch on the mains
voltage. “ON“ will appear on the display.
• Release both buttons. The current temperature is shown in the display, the password is
reset to “111“.
CLEANING
Dust can be very easily removed using a soft, clean, long-bristled brush and a vacuum
cleaner.
If you want to wipe the display, use a clean soft dry cloth. Do not use aggressive detergents,
or there could be changes in colour. Do not press the display too fi rmly. This may lead to
scratch marks and/or damage the display.
HANDLING
• Observe all safety and mounting instructions contained in these operating instruc-
tions.
• Do not expose the product to the following unfavourable ambient conditions at the
site of installation:
- Damp or excess air humidity
- Extreme cold (<-5°C) or heat (>+55°C), direct sunlight
- Dust or fl ammable gases, fumes or solvents
- Strong vibrations, impacts or blows,
- Strong magnetic fi elds such as those found close to machinery or loudspeakers
• Only operate the temperature controller when it is fi rmly assembled in an en-
closed casing.
• When assembling and operating the device, make sure the cable to the sensor is
not bent or jammed.
DISPOSAL
Please dispose of the device, when it is no longer of use, according to the current
statutory requirements.
