PROGRAMMING TESTS VOLTECH AT3600 USER MANUAL
PAGE 3.4.36. VPN 98 - 024 TEST PROGRAM EDITOR
4. Enter the phase limits.
For phase tests, the convention of the result returned by the AT depends on the
minimum limit requested. If this limit is >0 the result returned is between 0
0
and
360
0
. If the minimum limit is >-180
0
, the result returned is between –180
0
and
180
0
, otherwise the result returned is between –360
0
and 0
0
. This is done to ensure
continuity of results and ease of setting limits irrespective of where the phasor
diagram is being checked.
5. Select ‘OK’. The test specification will then be displayed in the program window.
