PROGRAMMING TESTS VOLTECH AT3600 USER MANUAL
PAGE 3.4.56. VPN 98 - 024 TEST PROGRAM EDITOR
3. Select (mouse click the button) the integration time you require.
'Medium' is the default setting. 'Long' will give more stable readings (for tighter
limits) at the expense of an increased test time, and 'Short' will test at the
maximum speed, but may give a slightly noisier reading.
4. Enter the terminal names for the Energized High and Low Terminals.
Click on the arrow to the right of the fill-in box, and you will be provided with a
choice of available terminals; double-click on the one required.
5. Similarly, enter the names for the Measured Terminals.
6. Select (mouse click the button) the type of limits you require and enter the
values.
% Enter a nominal value and then the limits as negative and positive
percentage values.
>< Enter minimum and maximum values.
> Enter just a minimum value.
< Enter just a maximum value.
Note that the Measure button may be used here as outlined in section 3.9.
7. Click on the appropriate button to choose the polarity, or choose the ‘No Test’
button. (For ac measurements, use the positive polarity when the measured
winding has the same phase as the energized winding, use the negative polarity
when they have opposite phases.)
Select OK. The test specification will then be displayed in the program window.
