SPECIFICATIONS
INSTALLATION NOTES
Colours Matte White, Matte Black
Motor wattage 40W
Motor type DC
Air delivery 239m3 /min on high - 74m3 /min on low
Blades 3
Diameter 52”and 48”
Blade material ABS
Reverse mode Yes (button on remote)
Speed High 220RPM – Low 71RPM
Remote w/ LED 6 speed and w/o LED 5 speed remote included
Warranty 7 years
Weight 7KG
Maximum install angle 15 degrees
Lumen 90-1640lm (Adjust via up/down button on remote)
Light wattage 20W
Light voltage 36V
Light type LED
Tricolour 2700K – 4000K – 5700K (button on remote)
Remote frequency Nominal 434MHz
Depth from Ceiling 298mm
Optional Accessories 600mm Extension Rod
Canopy Diameter 150mm
Installation area Indoor, Covered outdoor
