volvik V1 - Outer View; LCD Display View

OUTER VIEW
10
1: 6x Eyepiece
2:”ON & Laser Fire “Switch
3:”Mode“Switch
4: Lens/Receiver
5: Lens/Emitter
6: Battery Compartment
1: “Main Range”- Direct Distance
2: Indicates Laser signal Transmission
3+6: Angle Measure & Compensation distance
4: Low battery indicator
5: VIBRATION indicator
7: Pin FINDER Function
LCD DISPLAY VIEW
