03 Your driving environment
Lighting
03
93
3. Start from the design line on the headlamp
lenses, see the dotted line on the side
94. Position the self-adhesive templates
at the right distance from each design line
using the illustration and the dimensions in
the following list:
•
A = LHD Right - approx. 86 mm
•
B = LHD Left - approx. 40 mm
•
C = RHD Right - 0 mm
•
D = RHD Left - approx. 96 mm
