pg. 61 Replacing bulbs
Replacing sealed beam headlamp units
1. Press the two plastic screws down and turn them 1/4 turn and remove them.
2. Lift up the rim slightly and remove it forwards.
3. Remove clip and rim. Lift out the headlamp unit.
4. Disconnect the socket contact.
Installation is done in the opposite way.
Check headlight alignment.
pg. 62 Replacing bulbs
