1996 Volvo 960
Position Connection
Max.
load
1 Earth (31) 4 A
2
High beam (56
A)
1 A
3 Rheostat (PR) 1 A
4 Battery + (30) 16 A*
Yellow connector (for telephone)
Position Connection
Max.
load
1 Earth (31) 4 A
2
Ignition positions I and
II
1 A
3
4 Battery + (30) 16 A*
* The maximum combined load for Position 4 - black connector + Position 4 - yellow connector is 16A.
pg. 6:18 Replacing wiper blades
