Max. torque (SAE J 1349) at rpm 199 ft. lbs. (274 Nm) at 4100 rpm
Number of cylinders 6
Bore 3.27" (83 mm)
Stroke 3.54" (90 mm)
Displacement 2.92 liters
Compression ratio 10.7:1
Valve clearance: Self-adjusting
All specifications are subject to change without notice.
pg. 9:4 Specifications
Cooling system
Type: Positive pressure, closed system
Thermostat-begins to open at 186°F (87°C)
Coolant: Volvo Genuine Coolant/Anti-freeze
Capacity: 10.5 qts (10 liters)
Fuel system
The engine is equipped with a sequential fuel injection system
Distributor ignition System
Firing order 1-5-3-6-2-4
Distributor ignition setting Not adjustable
Spark plugs Bosch FR 6 DC (or equivalent)
Spark plug gap 0.024-0.028" (0.6-0.7 mm)
Tightening torque 17.3-20.3 ft. lbs. (23-27 Nm)
pg. 9:5 Specifications
