Volvo S80 - 2003 - Replacing bulbs

Fuses in the trunk
The fuses in the trunk are located behind the left panel. When replacing a blown fuse, be sure to
replace it with a new one of the
same color and amperage
(written on the fuse).
Ordinary fuses
Location
Amperage
1 Rear electrical module, trunk lighting 10A
2 Rear fog light 10A
3 Brake lights 15A
4 Backup lights 10A
5 Rear window defroster, relay 15I -
accessories
5A
6 Trunk release 10A
7 Folding rear head restraints 10A
8 Central locking rear doors/fuel filler door 15A
9 Trailer hitch (30 feed) 15A
10 CD changer, VNS 10A
11 Accessory control module (AEM) 15A
12 -
13 -
14 Brake lights 7.5A
15 Trailer hitch (15I feed) 20A
16 Electrical socket in trunk - accessories 15A
17 -
18 -
