11
IMG-294123
Remove the protective tape from the Velcro fasteners.
12
IMG-285836
Connect the gray 2 pin and green 5 pin pre-routed connector to
the trailer module (TRM).
Measure as illustrated and press the trailer module (TRM) onto
the cleaned surface. Ensure that the module's left long side is
not against the floor's vertical bend.
Installation instructions, accessories
Volvo Car Corporation Gothenburg, Sweden
