TECHNICAL SPECIFICATION / TECHNISCHE SPECIFICATIE / TECHNISCHE
DATEN / ESPECIFICACIONES TÉCNICAS / SPÉCIFICATIONS TECHNIQUES /
SPECYFIKACJA TECHNICZNA / TECHNICKÁ SPECIFIKACE
Input connections : 3.5mm Jack, 6.3mm Jack, SD, USB, XLR (3-pin)
Output connections : 6.3mm Jack
Output power: Max : 800W
Output power: Speaker : 500W
Amount of tweeters : 1
Diameter woofer : 10"
Magnet type : Ferrite
Frequency response : 50 - 20.000 Hz
Impedance : 8 Ohm
SPL @ 1W/1m : 90dB
SPL max : 117dB
Dimensions (L x W x H) : 670 x 370 x 689 mm
Dimensions: Per speaker : 290 x 340 x 530mm
Weight (kg) : 29,80
Weight: Satellite (kg) : 8.1
The specifications are typical. The actual values can slightly change from one unit to the other. Specifications can be changed
without prior notice.
The products referred to in this manual conform to the European Community Directives to which they are subject:
Tronios B.V.,
Bedrijvenpark Twente Noord 18,
7602KR Almelo, The Netherlands
