Vortex CROSSFIRE User Manual

3
5 6
www.vortexoptics.com www.vortexoptics.com
Attach the padded neckstrap to the binocular in
three simple steps. Begin with the right barrel of the
binocular and repeat the process for the left barrel.
The Neckstrap
1. Push a few inches of the
strap through the neckstrap
attachment point on the
binocular.
2. Loop the strap over the
attachment point, then
thread the strap through
the strap buckle.
3. Secure the end of the
strap by slipping it
through the strap loop.
IPD
The eyecups on the Crossfire binocular twist up and
down so any viewer can take advantage of the long eye
relief and enjoy comfortable, full-field viewing.
With eyeglasses or sunglasses,
retract the eyecups.
Without eyeglasses or sunglasses,
extend the eyecups.
Adjusting the Eyecups.
The twist-up eyecups are built on a solid frame and
covered with rubber.
Adjusting the Interpupillary Distance.
The interpupillary distance (IPD) is the distance
between the centers of the left and right eye pupils.
Match the IPD of your eyes
to that of the binocular by
rotating the binocular barrels
inward or outward until you
see a single image that is free of
shading.
Customizing the Crossfire

Vortex CROSSFIRE Specifications

General

Exit pupil	4.3 mm
Eye relief	15 mm
Prism type	Roof
Waterproof	No
Magnification	10 x
Product color	Black, Green
Objective diameter	42 mm
Closest focusing distance	2.43 m
Field of view (at 1000 m)	99.6 m
Interpupillary distance (max)	76 mm
Interpupillary distance (min)	56 mm
Adjustable interpupillary distance	Yes

Weight and Dimensions

Depth	- mm
Width	129.54 mm
Height	152.4 mm
Weight	660.54 g
