Center Focus
Diopter Ring
Prism Housing
Objective
Lenses
Center Hinge
Tripod Adapter
Socket
Neckstrap
Attachment
Point
The Diamondbacks are rugged roof prism binoculars.
The waterproof, dust proof, and internally fogproof
design features an internal focusing mechanism, o-rings
at all open points, and argon gas purging.
Rugged Design
Adjustable
Eyecup
The Diamondback binocular comes with two tethered
objective lens covers and a one-
piece rainguard that covers the
eyepieces. For convenience, the
rainguard can be attached to the
neckstrap where it is within easy
reach. Simply slip the neckstrap
through the attachment point on
the rainguard before connecting
the neckstrap to the binocular.
The Lens Covers
The custom-molded case of the Diamondback provides
protection for the
binocular when not
in use. For an easy
carry in the field,
clip the woven
nylon neckstrap
onto the case.
The Case
Preparing the Diamondback for Use
