Vortex SOLO R User Manual

5 4
tactical monocular
R/T
Basic OperatiOn
Adjusting the Focus
Designed for quick
single-handed
operation, simply
place the thumb and
forefinger on the focus
wheel and turn to
move lens forward
or backward.
Adjusting the Eyecup
The heavy duty flared rubber
eyecup on the Solo Tactical R/T
monocular folds up and down
for optimal viewing with or
without eyeglasses.
• Flared eyecup blocks stray light when fully extended.
• Eyecup folds down for viewing with eyeglasses.
Rotate
to focus
reticle
Rotate
to focus
• Top focus wheel adjusts the reticle.
• Bottom focus wheel adjusts the image.
Adjustable flared eyecup
Attaching the Lanyard
Attach lanyard in a few simple steps:
1. Detach clip from the
lanyard.
2. Push the loop end through
the attachment point on the
monocular.
3. Pull the clip through the
loop and cinch tight.
4. Re-attach the clip to lanyard.

Vortex SOLO R Specifications

General

Magnification	8x
Objective Lens Diameter	36 mm
Exit Pupil	4.5 mm
Angular Field of View	7.5 degrees
Waterproof	Yes
Fogproof	Yes
Lens Coating	Fully Multi-Coated
Focus Type	Center Focus
Linear Field of View	393 feet/1000 yards
Width	5.1 inches
Prism System	Roof
Prism Glass	BaK-4
