Vortex SOLO R User Manual

9 8
tactical monocular
R/T
The R/T ranging reticle is based on a form of angular
measurement called the milliradian (mrad for short). These
angular measurements allow a user to calculate ranges
when comparing the reticle to objects of known dimension.
The key to effective ranging using this reticle is knowing
common objects in your vicinity and their measurements.
Using the r/t ranging reticLe
28cm / 11”
50cm / 20”
35cm / 14”
44cm / 17”
79cm / 31”
All silhouette
dimensions are
accurate at the listed
ranges.
The R/T reticle uses a
system that is based on a
silhouette for quick ranging.
Subtensions
5 mrad
Fine crosshair thickness
subtends .05 mrad
Heavy crosshair thickness
subtends .5 mrad
1 mrad

Vortex SOLO R Specifications

General

Magnification	8x
Objective Lens Diameter	36 mm
Exit Pupil	4.5 mm
Angular Field of View	7.5 degrees
Waterproof	Yes
Fogproof	Yes
Lens Coating	Fully Multi-Coated
Focus Type	Center Focus
Linear Field of View	393 feet/1000 yards
Width	5.1 inches
Prism System	Roof
Prism Glass	BaK-4
