VULTURE
®
HD
BASIC OPERATION
Adjust the Eyecups
The eyecups on a Vulture
®
HD
binocular twist up and down so
any viewer can see the full field
and enjoy comfortable viewing—
with or without eyeglasses.
When not using eyeglasses or
sunglasses, keep the eyecups fully extended. For best viewing
through eyeglasses, twist eyecups down.
Adjust the Interpupillary Distance
The interpupillary distance (IPD) is the distance between the centers
of the left and right eye pupils. Match your eyes’ IPD to the binocular
so you see a single image free of shading.
Objective Lens
IPD
Distance between the
centers of the ocular lenses.
Twist-up Eyecup
Strap
Attachment
Tripod Adapter Socket
Ocular Lens
Rotate the binocular barrels
inward or outward to line your
eyes up with ocular lenses.
Images are for representation only. Product may vary slightly from what is shown.
Center Focus
Diopter
