SPECIFICATION
AC30C2X
• Dimensions (W x D x H): 702 x 265 x 556 mm / 27.64 x 10.43 x 21.89 inches
• Weight: 33.4 kg / 73.59 lbs.
• Output Power: 30 Watts RMS into 16 Ohms
• Speaker: 2 x 12" 8 ohm Celestion Alnico Blue
• Inputs: Normal input jack (high and low), Top Boost input jack (high and low), FX RETURN
jack, Footswitch jack
• Outputs: External loudspeaker jack, Extension loudspeaker jack, FX SEND jack
• Options: VFS2A Footswitch
AC30C2
• Dimensions (W x D x H): 702 x 265 x 556 mm / 27.64 x 10.43 x 21.89 inches
• Weight: 32.2 kg / 70.99 lbs.
• Output Power: 30 Watts RMS into 16 Ohms
• Speaker: 2 x 12" 8 ohm Celestion G12M Greenback
• Inputs: Normal input jack (high and low), Top Boost input jack (high and low), FX RETURN
jack, Footswitch jack
• Outputs: External loudspeaker jack, Extension loudspeaker jack, FX SEND jack
• Options: VFS2A Footswitch
AC15C1
• Dimensions (W x D x H): 602 x 265 x 456 mm / 23.70 x 10.43 x 17.95 inches
• Weight: 22 kg / 48.50 lbs.
• Output Power: 15 Watts RMS into 16 Ohms
• Speaker: 1 x 12" 16 ohm Celestion G12M Greenback
• Inputs: Normal input jack, Top Boost input jack, Footswitch jack
• Outputs: External loudspeaker jack, Extension loudspeaker jack
• Options: VFS2A Footswitch
*Specifications and appearance are subject to change without notice for improvement.

Vox AC15C1 Specifications

General

Number of Channels	2
Total Power	15W
Speaker	1 x 12" Celestion G12M Greenback
Preamp Tubes	3 x 12AX7
Power Tubes	2 x EL84
Reverb	Yes
Tremolo	Yes
EQ	Bass, Treble
Inputs	2 x 1/4" (Normal, Top Boost)
Outputs	1 x 1/4" (External Speaker)
Depth	10.43"
Type	Tube
Footswitch I/O	1 x 1/4" (Reverb, Tremolo)
Weight	48.5 lbs
